60W Public Address (PA) Amplifier With Bluetooth

Designed as an all-in-one compact amplifier for retail music systems and small scale PA systems requiring 100V line output, Bluetooth connectivity and telephone paging input. This 60W desktop amplifier offers Class-D performance in a compact package with 3 pin XLR balanced input, two stereo RCA inputs (music & telephone paging), plus wireless audio streaming via Bluetooth. Also available in 30W and 120W, it makes an ideal zone amplifier or small to medium scale 100V line PA solution for retail and hospitality requirements.

Features

• 100V, 70V and 4Ω outputs
• Stereo RCA music and telephone paging inputs
• 3 pin XLR balanced microphone input
• Adjustable VOX muting
• Adjustable paging level
• Ground lift switch
• Individual mic and music level adjustment
• Bass and treble adjustments

Specifications

• Input sensitivity for full output at maximum gain
• Microphone Channels: -50dB ±3dB
• LINE, AUX Channels: -6dB ±3dB
• Frequency Response (@ 1W speaker out): 8Hz~17kHz
• Tone Controls
• 100Hz, 10kHz: ±10dB ±3dB
• Signal to Noise Ratio at rated power output: >80dB
• Crosstalk at all control maximum: -65dB at 1kHz
• Rated Output Power at THD 1.0%: 60 Watts
• Rated Output Power at (THD) at 1kHz rated power: Less than 1.0%
• Power Band Width at 1kHz from speaker out tap: 80Hz~17kHz with less than 1.0% THD
• Mute Function Priority: Telephone paging, Mic VOX > Bluetooth > Mic, Music
• Operating Temperature/Humidity at non-condensing: 0°~40°C at 90% humidity
• Output Voltage and Impedance
• 4Ω: 15V
• 70V: 82Ω
• 100V: 166Ω
• Mechanical
• Cooling: Convection Cooled
• Dimensions: (Width/Height/Depth) 280W x 70H x 190Dmm
• Weight: 2.50kg
